LSI MegaRAID SAS User Manual

LSI Corporation
- 70 -
6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2012
Chapter 3: MegaRAID SAS RAID Controller Characteristics
Technical Specifications
Part number (continued)  MegaRAID SAS 9286CV-8e RAID controller: 25421
 MegaRAID SAS 9286CV-8eCC RAID controller: 25421
Operating voltage +3.3 V, +12 V
Card size  MegaRAID SAS 9240-4i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9240-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9260-4i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9260-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9260-16i RAID controller: Standard-height PCI Express adapter
card size (111.15 mm x 167.64 mm)
 MegaRAID SAS 9260CV-4i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9260CV-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9260DE-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9261-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9265-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9265CV-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9266-4i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9266-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9270-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9271-4i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9271-8i RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9271-8iCC RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9280-4i4e RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9280-8e RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9280DE-8e RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9280-16i4e RAID controller: Standard-height PCI Express
adapter card size (111.15 mm x 167.64 mm)
 MegaRAID SAS 9280-24i4e RAID controller: Standard-height PCI Express
adapter card size (111.15 mm x 167.64 mm)
 MegaRAID SAS 9285-8e RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
 MegaRAID SAS 9285CV-8e RAID controller: Low-profile PCI Express adapter
card size (68.90 mm x 167.65 mm)
Table 21 RAID Controller Specifications (Continued)
Specification
MegaRAID SAS 9240, SAS 9260, SAS 9261, SAS 9265, SAS 9266, SAS 9270,
SAS 9271, SAS 9280, SAS 9285, and SAS 9286 RAID Controllers

LSI MegaRAID SAS Specifications

General

RAID Levels	0, 1, 5
Ports	8
Form Factor	Low Profile
Operating Systems Supported	Windows, Linux, VMware
SAS Ports	8
BBU Support	Optional
Operating Temperature	0°C to 55°C
