LSI MegaRAID SAS User Manual

LSI Corporation
- 27 -
6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2012
Chapter 2: MegaRAID SAS Hardware Installation
SAS Device Cables and Connectors
Figure 8 Connecting the MegaRAID SAS 9280-8e RAID Controller to a Drive Enclosure
To Drive Enclosure
Mini SAS x4
Cable Plug
Connector
85040-10
iBBU (Top View)
Pb
LSI 31503-00 Rev. B
Caution:
Danger of explosion if battery is incorrectly replaced.
Replace with same or equivalent type recommended by manufacturer.
Dispose
o
f used
b
atteries according to
m
anufacturer's
i
nstructions.
e1
Pb
A
SSEMBLEDIN USA.
WWYYN0000

LSI MegaRAID SAS Specifications

General

RAID Levels	0, 1, 5
Ports	8
Form Factor	Low Profile
Operating Systems Supported	Windows, Linux, VMware
SAS Ports	8
BBU Support	Optional
Operating Temperature	0°C to 55°C
