Chapter 3: MegaRAID SAS RAID Controller Characteristics
6Gb/s MegaRAID SAS RAID Controller Family
3.1.2.2 MegaRAID SAS 9260-16i RAID Controller – Board Layout and Jumper/Connector Information
This subsection provides the board layout, and the connector and jumper information for the MegaRAID SAS
9260-16i RAID controller. The following figure shows the jumpers and connectors on the MegaRAID SAS 9260-16i
RAID controller.
Figure 11 Card Layout for the MegaRAID SAS 9260-16i RAID Controller
NOTE Pin 1 on the headers and connectors is highlighted in red in the previous figure.
85068-00
J2B1
Ports
0-3
J2B2
Ports
4-7
J3B1
Ports
8-11
J4B2
Ports
12-15
J1A2
J1B1
J1B3
J1C1
J2D1
J1L1
on
back
J4A2
J5A2
J4A3
J5B3
J4A1
J4A4
