6Gb/s MegaRAID SAS RAID Controllers User Guide
August 2012
Chapter 3: MegaRAID SAS RAID Controller Characteristics
6Gb/s MegaRAID SAS RAID Controller Family
J1A7
I
2
C Enclosure Management connector
3-pin connector
Supports SES (SCSI enclosure services) over I
2
C through an
internal I
2
C backplane cable.
J1B1 Serial EEPROM (SBR) 2-pin connector
Provides controller information, such as the serial number,
revision, and manufacturing date. The default is no
shunt installed.
J2B1 x4 SAS Ports 0 to 3 Internal connector SFF-8087 mini SAS 4i internal connector
Connects the controller by cable to SAS drives or
SATA 2 drives.
J2B2 x4 SAS Ports 4 to 7 Internal connector SFF-8087 mini SAS 4i internal connector
Connects the controller by cable to SAS drives or
SATA 2 drives.
J2B3 Advanced Software Options Hardware Key header 3-pin header
Enables support for the Advanced Software Options
features, which include CacheCade, FastPath, Recovery, and
SafeStore disk encryption.
J2B4 Standard Edge Card connector The RAID controller interfaces with the host system though a
standard edge card.
This interface provides power to the board and an I
2
C
interface connected to the I
2
C bus for IPMI.
J5A1 Serial Universal Asynchronous Receiver/Transmitter
(UART) connector for the expander
4-pin connector
Reserved for LSI use.
J5B1 Board-to-Board Mezzanine connector 240-pin 02 DDR3 nonvolatile memory module interface
Connects a CacheVault Flash Module, CVFM03, directly to
the RAID controller. The CVFM03 module connects to a
CacheVault Power Module 02, CVPM02, that is mounted on a
remote mount board.
Refer to the MegaRAID SAS 9285CV-8e RAID Controller Quick
Installation Guide for the procedure used to connect the
CVFM03 module to the CVPM02 module.
J6A1 Serial Universal Asynchronous Receiver/Transmitter
(UART) connector for the expander
4-pin connector
Reserved for LSI use.
Table 9 MegaRAID SAS 9265CV-8i RAID Controller – Jumpers and Connectors (Continued)
Jumper/
Connector
Type Description
J1A7
1
2
3
