LSIS 004iC5-1 User Manual

1. Basic information and precautions
1-2
1.2 Product Details
1.2.1 Appearance
1.2.2 View without the front cover
Refer to Page 1-3 for front cover removal.
Front Cover:
Remove it when
wiring and changing
parameter setting.
Bottom Cover:
Remove it when
wiring input power
and motor.
Status LED
Display
Window
Inverter
Nameplate
4-Way button for
parameter setting
(Up/Down/Left/
Right key)
Analog
Input/Output
Terminal
NPN/PNP
Select
Switch
Keypad
Potentiometer
STOP/RST
Button
RUN
Button
Inverter Ground
Terminal
☞Caution: Remove
the bottom cover
to access the
terminal.
Body slot: When front
cover is pulled back till
this line and lifted up,
it can be removed
from main body. See
Page 1-3.
