LSIS Starvert iG5A Series - Page 11

P1
P2
CM
P3
P4
P5
CM
P6
P7
P8
24
R
S
T
G
U
V
W
AM
CM
3A
3C
3B
MO
MG
S+
S-
DB resistor
(Optional)
3 phase AC input
(Rated input voltage)
VR
V1
I
CM
B1 B2
A contact output
A/B contact common
B contact output
FX (Forward run)
RX (Reverse run)
Input signal common
BX (Emergency stop)
RST (Trip reset)
JOG (Jog operation)
Input signal common
Multi-step freq. - Low
Multi-step freq. - Middle
Multi-step freq. - High
24V output
Ground
10V power supply for potentiometer
Freq. Setting Voltage signal input: -10~10V
Freq. Current signal input: 0~20mA
Input signal common
Multi-function open
collector output
MO Common
Potentiometer
(1kohm, 1/2W)
RS-485 communication terminal
Multi-function
analog output
signal: 0~10V
Wiring
0.4~7.5kW
11
Compact & Powerful Drive iG5A
Drive Starvert iG5A Series
