LED
display
Address for
communication
Parameter
name
Min/Max
range
Description
Adj.
during run
Factory
defaults
Drive Group
1) This function can be available with iG5A Communication Option Module.
A100
[Frequency 0 ~ 400
command] [Hz]
A101 [Accel time]
0 ~ 6000
A102 [Decel time]
[Sec]
A103 [Drive mode] 0 ~ 3
A104
[Frequency
0 ~ 7
setting method]
A105
[Multi-Step
frequency 1]
A106
[Multi-Step 0 ~ 400
frequency 2] [Hz]
A107
[Multi-Step
frequency 3]
A108 [Output current]
A109 [Motor RPM]
A10A [Drive DC
link voltage]
A10B
[User display
select]
This parameter sets the frequency that the drive is commanded
to output.
During Stop: Frequency Command
During Run: Output Frequency
During Multi-step operation:
Multi-step frequency 0.
It cannot be set greater than F21- [Max frequency].
During Multi-Accel/Decel operation, this parameter serves as
Accel/Decel time 0.
0 Run/Stop via Run/Stop key on the keypad
1
FX: Motor forward run
Terminal operation
RX: Motor reverse run
2
FX: Run/Stop enable
RX: Reverse rotation select
3 RS485 communication
4 Set to Field Bus communication
0
Digital
Keypad setting 1
1 Keypad setting 2
2 V1 1: -10 ~ +10 [V]
3 V1 2: 0 ~ +10 [V]
4 Analog Terminal I: 0 ~ 20 [mA]
5 Terminal V1 setting 1 + Terminal I
6 Terminal V1 setting 2+ Terminal I
7 RS485 communication
8 Digital Volume
9 Set to Field Bus communication
Sets Multi-Step frequency 1 during Multi-step operation.
Sets Multi-Step frequency 2 during Multi-step operation.
Sets Multi-Step frequency 3 during Multi-step operation.
Displays the output current to the motor.
Displays the number of Motor RPM.
Displays DC link voltage inside the drive.
This parameter displays the item selected at H73- [Monitoring
item select].
vOL Output voltage
POr Output power
tOr Torque
0.00 O
5.0 O
10.0 O
1 X
0 X
10.00 O
20.00 O
30.00 O
- -
- -
- -
vOL -
0.00
ACC
dEC
drv
Frq
St1
St2
St3
CUr
rPM
dCL
vOL
Function List
1)
1)
25
Compact & Powerful Drive iG5A
Drive Starvert iG5A Series
