LSIS Starvert iG5A Series User Manual

3A 3B 3C P5 CM P6 P7 P8 VR V1 I AM
MO MG 24 P1 P2 CM P3 P4 S
-
S
+
Multi-function input T/M 1-8
Common terminal
Power supply for external
potentiometer
Input terminal for voltage operation
Input terminal for current operation
Multi-function analog output terminal
Multi-function terminal for open collector
Ground terminal for external power supply
24V external power supply
Multi-function relay output A contact
Multi-function relay output B contact
Common for multi-function relays
Description
Screw size
Single wire Stranded
Torque (Nm)
Specification
P1~P8
CM
VR
V1
I
AM
MO
MG
24
3A
3B
3C
1) Use the recommended tightening torque when securing terminal screws.
※ When you use external power supply (24V) for multi-function input terminal (P1~P8), apply voltage higher than 12V to activate.
※ Tie the control wires more than 15cm away from the control terminals. Otherwise, it interferes front cover reinstallation.
Terminal
Wire size (mm
2
)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
M2.6
M2.6
M2.6
M2.6
M2.6
M2.6
M2.6
M2.6
M2.6
M2.6
M2.6
M2.6
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
Output voltage: 12V
Max. output current: 100mA
Potentiometer: 1~5kohm
Max. input voltage:
-12V~+12V input
0~20mA input
Internal resistor: 500ohm
Max. output voltage: 11V
Max. output current: 100mA
Below DC 26V,100mA
Max. output current: 100mA
Below AC 250V, 1A
Below DC 30V, 1A
1)
iG5A
Terminal Configuration
Control terminal specifications
