Moving to other groups
Parameter group
Moving to other groups using the Right (
▶
) key Moving to other groups using the Left (
◀
) key
Description
Drive group
Function group 1
Function group 2
I/O (Input/Output) group
Basic parameters necessary for the drive to run. Parameters such as Target frequency, Accel/Decel time settable.
Basic function parameters to adjust output frequency and voltage.
Advanced function parameters to set parameters for such as PID Operation and second motor operation.
Parameters necessary to make up a sequence using multi-function input/output terminal.
1) Target frequency can be set at 0.0 (the 1st code of drive group). Even though the preset value is 0.0, it is user-settable.
The changed frequency will be displayed after it is changed.
1) 1)
There are 4 different parameter groups in iG5A series as shown below.
iG5A
Moving to Other Groups
Parameter groups
16
