LSIS XBL-C21A User Manual

Chapter 2 specification
2-3
2.2 Performance Specification
(1) Built-in Cnet performance specification
Performance specification of XGB built-in Cnet is as follows.
Item
Specification
Channel 1
Channel 2
Serial communication
method
RS-232C RS-485
Modem connection
function
- -
Operation
mode
(Operation
define by
channel)
P2P
Act as communication client
- XGT dedicated protocol client
- Modbus ASCII/RTU client
- User defined communication
- LS Bus Client
Notes 1)
Server
- XGT dedicated protocol server
- Modbus ASCII/RTU server
Data
type
Data bit
7 or 8
Stop bit
1 or 2
Parity
Even/Odd/None
Synchronization type
Asynchronous type
Transmission speed
(bps)
1200/2400/4800/9600/19200/38400/57600/115200 bps available
Station No. setting
Setting range: 0~255
Max. station No. available: 32 stations
Transmission
distance
Max. 15m Max. 500m
Diagnosis function Check available by XG-PD diagnosis service
Notes
Notes 1) < LS Bus Client applicable version>
Series XBM XBCH XBCSU XBCS XBCE XG5000
Version V3.40 or above
V2.30 or above
V1.40 or above
V1.30 or above
V1.20 or above
V3.69 or above
Series XBCEX XBCEB XECH XECSU XECE -
Version V1.01 or above
V1.01 or above
V1.70 or above
V1.30 or above
V1.10 or above
-
