LSIS XBL-C21A User Manual

Appendix 2 Communication Relay List (L)
A-４
Appendix 2.2 Network Register (N) List
Here describes about network register ( P2P parameter: 1~3, P2P block: 0~31 )
Device IEC type Keyword Type Description
N000
%NW000
_P1B00SN Word
Saves another station no. of P2P parameter 1, 00 block.
N0000~0004
%NW0001
~0005
_P1B00RD
1
Word
Saves area device 1 to read P2P parameter 1, 01 block.
N005
%NW006
_P1B00RS
1
Word
Saves area size 1 to read P2P parameter 1, 01 block.
N0006~0009
%NW0007
~0011
_P1B00RD
2
Word
Saves area device 2 to read P2P parameter 1, 01 block.
N010
%NW012
_P1B00RS
2
Word
Saves area size 2 to read P2P parameter 1, 01 block.
N0011~0014
%NW0013
~0017
_P1B00RD
3
Word
Saves area device 3 to read P2P parameter 1, 01 block.
N015
%NW018
_P1B00RS
3
Word
Saves area size 3 to read P2P parameter 1, 01 block.
N0016~0019
%NW0019
~0023
_P1B00RD
4
Word
Saves area device 4 to read P2P parameter 1, 01 block.
N020
%NW024
_P1B00RS
4
Word
Saves area size 4 to read P2P parameter 1, 01 block.
N0021~0024
%NW0025
~0029
_P1B00W
D1
Word
Saves area device 1 to save P2P parameter 1, 01 block.
N025
%NW030
_P1B00WS
1
Word
Saves area size 1 to save P2P parameter 1, 01 block.
N0026~0029
%NW0031
~0035
_P1B00W
D2
Word
Saves area device 2 to save P2P parameter 1, 01 block.
N030
%NW036
_P1B00WS
2
Word
Saves area size 2 to save P2P parameter 1, 01 block.
N0031~0034
%NW0037
~0041
_P1B00W
D3
Word
Saves area device 3 to save P2P parameter 1, 01 block.
N035
%NW042
_P1B00WS
3
Word
Saves area size 3 to save P2P parameter 1, 01 block.
N0036~0039
%NW0043
~0047
_P1B00W
D4
Word
Saves area device 4 to save P2P parameter 1, 01 block.
N040
%NW0048
_P1B00WS
4
Word
Saves area size 4 to save P2P parameter 1, 01 block.
N0041~0081
%NW0049
~0097
- Word
Saving area of P2P parameter 1, 01 block.
N0082~0122
%NW0098
~0146
- Word
Saving area of P2P parameter 1, 02 block. P2P
N0123~1311
%NW0147
~1567
- Word
Saving area of P2P parameter 1, 03~31 block.
N1312~2623
%NW1568
~3135
- Word
Saving area of P2P parameter 2.
N2624~3935
%NW3136
~4703
- Word
Saving area of P2P parameter 3.
Remark
 In XGB S type, Network register is available only monitoring. (Read Only)
