Page #11 background image
Instruction Manual
______________________________________________________________________
_____________________________________________________________________________
BE6043-16 Stand Alone Multipoint System LumaSense Technologies A/S
Page 11 of 25
By using the keys described above follow the path:
1) Press the SET-UP key on the front panel
2) Select Gas Monitor
3) Select Measurement
4) Select Monitoring Task
Now You are in the Monitoring task set-up menu. By following this
path select Gases to be measured, if Water Vapor Interference
and/or cross interference compensation is to be performed.
In the Monitoring task menu it is also possible to select whether
the sampling should run continuously (as fast as possible) or with
a defined sequence interval. The sequence interval is the time
between the end of one sequence and the start of the next one.
Please be aware to set-up the Monitor to Store Measurement
History if all measurement values are to be stored in the Memory.
If the Store History it set to NO only the last measured, value is
stored.
4.2 Set-up concentration units
The default units are:
- Humidity: mg/m
3
- Pressure: kPa
- Gas Concentration: mg/m
3
- Length: m
- Temperature: K
These units can be changed :
1) Press the SET-UP key on the front plate.
2) Following the Quick Set-up guide (Figure 3) and the text on the
display select Gas MonitorConfiguration…Units.
Now You are in the unit set-up menu. Select the desired units for the
measurement task.
If mg/m
3
is to be used remember to select the Normalization
Temperature in the Environment branch see section 4.3.
4.3 Set-up Environment
In the Environment set-up menu the tube flush set-up can be defined.
1) Press the SET-UP key on the front plate.
2) Following the Quick Set-up guide (Figure 3) and the text on the display
select Gas Monitor…Measurement…Environment.
3) In the Environment set-up menu. Select the desired Flushing mode.
Auto: the tube length is to be define
Fixed time: the chamber- and tube-flush times are to be defined.
The minimum and maximum values for the tube flush settings are:
