BE6043-16 Stand Alone Multipoint System LumaSense Technologies A/S
Page 21 of 25
8.0 Viewing data using the Gas Monitor.
8.1 Viewing Measurement Data
When the first measurement cycle is complete the Monitor will
automatically display the results and update them every time a new
measurement cycle is completed. An example is shown below:
This display gives the overview of the gas/vapour concentrations last
measured on the displayed Channel (CH) number (no) – CH ( no) will
be from 1-24 depending on the configuration and set-up.
If no pre-set monitoring period is defined, then to stop the monitoring
task, press MEASURE and S3.
From above screen (main screen) press twice.
Now by using
& Using these push-buttons users can scroll “horizontally”
through any vertical level of data. For example, if the statistical
analysis of the measurement results for water-vapour are displayed on
the screen, then by using you can read the statistical analysis of the
measurement results for gas A, B, C etc. and then proceeding to the
next channel number.
This push-button allows the user to scroll “vertically”
downwards through the list of measurement results
for the selected Gas at the Selected Channel.
This push-button allows the user to scroll “vertically”
upwards through the list. The measurement list is a
closed loop. This loop also have information on the
measurement set-up as an example the sample
sequence showing the active channels.
The push-buttons and have a repetitive function, which means
that if they are pressed continuously they will allow the user to scroll
very quickly through a list.
