Instruction Manual
______________________________________________________________________
_____________________________________________________________________________
BE6043-16 Stand Alone Multipoint System LumaSense Technologies A/S
Page 17 of 25
5.2 Relay output connector Gas Mode.
Relay output connector Gas
Mode.
D-sub pin
No.
Description
1
R1 COMMON
Filter A limit 1
2
R1 NO
3
R1 NC
4
R2 COMMON
Filter A limit 2
5
R2 NO
6
R2 NC
7
R3 COMMON
Filter B limit 1
8
R3 NO
9
R3 NC
10
R4 COMMON
Filter B limit 2
11
R4 NO
12
R4 NC
13
R5 COMMON
Filter C limit 1
14
R5 NO
15
R5 NC
16
R6 COMMON
Filter C limit 2
17
R6 NO
18
R6 NC
19
Not used
Not used
20
R7 COMMON
Filter D limit 1
21
R7 NO
22
R7 NC
23
R8 COMMON
Filter D limit 2
24
R8 NO
25
R8 NC
26
R9 COMMON
Filter E limit 1
27
R9 NO
28
R9 NC
29
R10 COMMON
Filter E limit 2
30
R10 NO
31
R10 NC
32
R11 COMMON
Filter W limit 1
33
R11 NO
34
R11 NC
35
R12 COMMON
Filter W limit 2
36
R12 NO
37
R12 NC
VO: Voltage output.
CO: Current output.
NO: Normally opened.
NC: Normally closed.
