The entry into the mode of alarm setting is not protected by the
access code.
Alarms are active if they were attributed, i.e. if a measured quantity
different than zero (table 5) has been attributed to them. One must
notice that alarms concern chosen quantities in the basic configura-
tion mode
S and they are not related with quantities displayed
on the page. If the quantity value related to the alarm exceeds the
declared threshold, the two-state output corresponding to this alarm
will be switched on (relay) and the symbol Ai will be lighted. If the
quantity value decreases below the alarm threshold, the two-state
output is switched off, but the Ai signalling remains until the time of
its cancellation by means of the ESC key.
The Aion < AioF setting causes the alarm inverse action, i.e. the
output is switched on if the prescribed value decreases below the
Aion value and the output is switched off if the value increases above
the AioF threshold.
Table 4
Manu-
factu-
rer’s
values
Item Parameter name
Designa
tion
Range Notice/description
1 Two state output 1-
quantity
2
2
Two state output 1-
switch on value
3
Two state output 1-
switch off value
4 Two state output 2-
quantity
5
Two state output 2-
switch on value
6
Two state output 2-
switch off value
7 Two state output 3-
quantity
16
101
99
9
101
Quantity code acc.
table 5
99
Two state output 3-
switch on value
Two state output 3-
switch off value
Delay of alarm action
A1_n
A1on
A1oF
A2_n
A2on
A2oF
A3_n
A3on
A3oF
ALdt
0, 1...34
0...120 [%]
0...120 [%]
Quantity code acc.
table 5
0, 1...34
0...120 [%]
0...120 [%]
0, 1...34
Quantity code acc.
table 5
8
9
10
0...120 [%]
101
0...120 [%]
0...100 sec
Time lag of alarm
switching on
99
0
