3
Service manual
POWER NETWORK PARAMETER ANALYSER
N10
1. APPLICATION .........................................................................5
2. METER SET ............................................................................5
3. INSTALLATION .......................................................................6
3.1. FITTING ...............................................................................6
3.2. EXTERNAL CONNECTION DIAGRAMS ......................................7
4. PROGRAMMING ..................................................................12
4.1. FACEPLATE DESCRIPTION
...................................................12
4.2. N10 OPERATING MODES
.....................................................14
4.2.1 MEASURING MODE
...........................................................15
4.2.1.1. Measurement of voltage and current harmonics
......................16
4.2.2. TIME SETTING MODE - t
....................................................17
4.2.3. PARAMETER CONFIGURATION MODE - S
............................18
4.2.4. ALARM CONFIGURATION MODE - A
....................................20
4.2.5. PAGE CONFIGURATION MODE - P
.....................................22
5. ERROR CODES ....................................................................25
6. TECHNICAL DATA ...............................................................27
7. ORDERING CODES .............................................................30
8. MAINTENANCE AND GUARANTEE ...................................31
March 2007 - KZ 1268/06
