4.2.5. Page configuration mode - P
This mode is used to select quantities displayed simultaneously on
the meter, i.e. to define user’s pages.
A list of possible quantities and their codes are inserted in the table 5.
Table 5.
00 Without quantity - display
extinguished
01 Phase 1 voltage U
1
(k)V L1
02 Line L1 current I
1
(k)A L1
03 Phase L1 active power P
1
(M,k)W L1 /-
04 Phase L1 reactive power Q
1
(M,k)VAr L1 /-
05 Phase L1 apparent power S
1
(M,k)VA L1
06 Phase L1 active power factor
(Pf
1
= P
1
/ S
1
) Pf
1
Pf L1 /-
07 Phase L1 t
1
factor (t
1
= Q
1
/ P
1
) t
1
t L1 /-
08 Phase L2 voltage U
2
(k)V L2
09 Line L2 current I
2
(k)A L2
10 Phase L2 active power P
2
(M,k)W L2 /-
11 Phase L2 reactive power Q
2
(M,k)VAr L2 /-
12 Phase L2 apparent power S
2
(M,k)VA L2
13 Phase L2 active power factor
(Pf
2
= P
2
/ S
2
) Pf
2
Pf L2 /-
14 Phase L2 t
2
factor (t
2
= Q
2
/ P
2
) t
2
t L2 /-
15 Phase 3 voltage U
3
(k)V L3
16 Line L3 current I
3
(k)A L3
17 Phase L3 active power P
3
(M,k)W L3 /-
18 Phase L3 reactive power Q
3
(M,k)VAr L3 /-
19 Phase L3 apparent power S
3
(M,k)VA L3
20 Phase L3 active power factor
(Pf
3
= P
3
/ S
3
) Pf
3
Pf L3 /-
21 Phase L3 t
3
factor (t
3
= Q
3
/ P
3
) t
3
t L3 /-
22 Average 3-phase voltage Us (k)V 1,2,3
23 Average 3-phase current Is (k)A L1,L2,L3
Code Quantity name
Symbol
Unit
Signal-
ling
Mark
