23
24 3-phase active power P (M,k)W L1,L2,L3 /-
25 3-phase reactive power Q (M,k)VAr L1,L2,L3 /-
26 3-phase apparent power S (M,k)VA L1,L2,L3
27 Active power factor (Pf= P/ S) Pf Pf L1,L2,L3 /-
28 Average 3-phase t( factor
(t= Q/P) t t L1,L2,L3 /-
29 Frequency f Hz
30 Voltage between lines L1-L2 U12 (k)V L1,L2
31 Voltage between lines L2-L3 U23 (k)V L2,L3
32 Voltage between lines L3-L1 U31 (k)V L3,L1
33 Average between lines voiltage U123 (k)V L1,L2,L3
34 15-minutes average active power PAV (M,k)W 1, 2, 3
35 3-phase active energy EnP (M,k)Wh L1,L2,L3 /-
36 3-phase reactive energy Enb (M,k)VArh L1,L2,L3 /-
37 3-phase apparent energy EnS (M,k)VAh L1,L2,L3
38 Active energy from external
counter EnPz (M,k)Wh
39 Reactive energy from external
counter Enbz (M,k)VArh
40 Apparent energy from external
counter EnSz (M,k)VA
41 Date - day, month
42 Date - year
43 Time - hours, minutes
44 Time - secondes
45 THD of the phase L1 voltage THD U1 V% L1
46 THD of the phase L2 voltage THD U2 V% L2
47 THD of the phase L3 voltage THD U3 V% L3
48 THD of the phase L1 current THD I1 A% L1
49 THD of the phase L2 current THD I2 A% L2
50 THD of the phase L3 current THD I3 A% L3
In the case of parameters 40...50, the denominations V and A have
got a conventional character distinguishing the given parameter, the
basic quantity in %.
