This effect enables you to setup a static level for the selected xture. Once the effect is assigned to the timeline the following
window is opened (if the effect is assigned to a color channel).
3 modes are available to setup a color :
- color picker
- preset colors (red, green, cyan...)
- manual selection of the RGB values
Note : it is possible to setup the duration of the effect by clicking on the left-side icon from
the toolbar.
Once the selection is made, you must select an effect from the “Effects” window and drag it to the timeline. It is not possible
to drag an effect is there is no xtures selected. Here is a brief
description of available effects :
– Constant level : enables to assign a constant DMX level to the selected xtures
(a static color for example)
– Gradient : enables to create a fade between 2 (or more) colors, from red to
green or from red to yellow, to blue, to green...
– Curve (advanced) : enables to assign a curve (wave form, square...)
to one ore several channels (R+G+B for example)
– Color : enables to assign a preset effect (chaser, rainbow...)
to the selected xtures
– Matrix effect : enables to assign a matrix effect (circle, square, rain...)
to the selected LED matrix
– Picture : enables to display a picture on the selected matrix
– GIF : enables to display an animated .gif le on the selected matrix
– Video : enables to display a video on the selected matrix
– Text : enables to write a text (static or dynamic) on the selected matrix
4.2.2.2.1. Static level
4.2.2.2. The effects
