Lumens VC-A61P User Manual

English - 27
1st Level
Major Items
2nd Level
Minor Items
3rd Level
Adjustment Values
Function Descriptions
System
Prompt
On / Off
Turn on/off the prompt information
on the display
IR Receive
On / Off
Tally Lamp
On / Off
Tally CMMD
Mode
Normal/ Link
Set whether the indicator light is
linked with RS232 command
 Normal (Not linked): The
indicator light switch and mode
shall be set separately.
 When the indicator light is on
and the default mode is off,
additional command is
required to set the indicator
light mode
 Setting indicator light mode
when the indicator light is off
will not trigger the indicator
light
 Link:
 When the indicator light is on,
the default mode is red light
 Setting indicator light mode
when the indicator light is off
will turn on the indicator light
Language
English / Chinese
Initial Position
Last MEM / 1st Preset
Set the camera lens to return to
the last operated position or the
first preset position after POWER
ON
< Remark > 1st Preset = Preset 0
Control Device
Encoder / Controller
Control Device setting,
Controller: for joystick
Encoder: for tracking system
Motionless
Preset
On / Off
When the function is enabled, the
screen will Freeze when Preset is
executed. Freeze will be released
after Preset is completed.
Control Port
RS-232/RS-422
Choose whether the control
interface used is RS-232 or
RS-422
Protocol
VISCA/Pelco D
Baud Rate
9600/38400
Choose the transmission speed of
the control signal
VISCA Address
0 ~ 7
Pelco D Address
1 ~ 255
The Protocol set to Pelco D allows
the camera ID address to be
assigned
