The remote control ID setting is only controlled after corresponding
to the Camera Select on the remote control
Network port supports routers or hubs of PoE++ (IEEE802.3bt)
with power supply
The USB port is for connecting to the USB port of the computer
and providing USB signal images
<Remark> Support up to 3840 x 2160/29.97p
HDMI 2.0 output (Audio output supported)
3G-SDI output(Audio output supported)
12G-SDI output (Audio output supported)
AC power supply connecting port
RS-232 output port, at most 7 cameras can be connected in a
serial connection
RS-232 input port, at most 7 cameras can be connected in a serial
connection
SDI Synchronous Source Input
Adjust the resolution setting. The default is 3840 x 2160/59.94p
RS-422 connecting port, at most 7 cameras can be connected in a
serial connection
