Lutron Electronics DS-2013SD User Manual

Power off Auto shut off saves battery life or
manual off by push button.
Operating 0 to 50 ℃.
Temperature
Operating Less than 85% R.H.
Humidity
Power Supply
* AC/DC power adapter is optional.
Alkaline or heavy duty DC 1.5 V battery
( UM4, AAA ) x 6 PCs, or equivalent.
* AC/DC power adapter is optional.
DC 9V adapter input. ( AC/DC power
adapter is optional ).
Power Current Normal operation ( w/o SD card save
data and LCD Backlight is OFF) :
Approx. DC 16 mA.
When " SD " save the data but and
LCD Backlight is OFF) :
Approx. DC 35 mA.
* AC/DC power adapter is optional.
If LCD backlight on, the power
consumption will increase approx.
DC 8 mA.
Weight 250 g/ 0.55 LB. (without battery)
Dimension 132 x 80 x 32 mm.
( 5.2 x 3.1 x 1.3 inch ).
Accessories
*
Instruction manual.........................................
1 PC
Included
*
Soft carrying case, CA-05A…………………………....
1 PC
*
Micophone with clip…………………………....
1 PC
*
Hanging unit ( with sticker ).............................
1 PC
Optional
*
Sound calibrator ( 94 dB ), SC-941.
Accessories
*
Sound calibrator ( 94/114 dB ), SC-942.
*
Sound wind shield ball, SB-01
*
SD Card ( 4 GB )
*
USB cable, USB-01.
*
RS232 cable, UPCB-02.
*
Data Acquisition software,
SW-E2005.
*
AC to DC 9V adapter.
5
