4-4-2 The Setting Function menu
* Folder Name : Set the expect folder name for SD CARD,
the range is between WTA01 and WTA10.
* File Name: Set the file name for SD CARD, It allows setting
50 filenames in this function.
* REC Date: Show the recorded time of existing files
( Year/Month/Date, Hour/Min./Sec. )
* Sampling Time : Set the sampling time from 2 to 7200 seconds.
* Delete File : To delete the existing data from SD CARD.
* SD Format : to Format SD CARD fast.
* PT : Set the potential transformer from 1 to 1000.
* CT : Set the current transformer from 1 to 600.
* Beep : Set to ON/OFF for buzzer.
* Clamp Type : Select the Clamp Type to CP-1201, CP-200
CP-2000, CP-3000 or Other Type.
* RS232 out Sel. : Set RS232 output function, maximum up
to nine items can be selected to output. screen 1 screen 2.
* Year : Set the year.
* Month : Set the month.
* Date : Set the date.
* Hour : Set the hour.
* Minute : Set the minute.
* Second : Set the second.
4-5 Setting function description before measuring
Press SETUP KEY to enter setting function screen, the
selected item will be displayed in highlight.
14
