5-7 Data Logger Function
A : Press REC KEY once to start the data record function.
A-1 : If the bottom right shows as " Change Card ", it
indicates the memory space is already full either or the
SD CARD exist some wrong.
A-2 : If the SD CARD is normal, the data logger function
will start to be executed.
V12: 0.0 V V1: 0.0 V A1: 0.00 A
V23: 0.0 V V2: 0.0 V A2: 0.00 A
V31: 0.0 V V3: 0.0 V A3: 0.00 A
P1: - 0.000 KW S1: 0.000 KVA Q1: - 0.000 KVAR
P2: - 0.000 KW S2: 0.000 KVA Q2: - 0.000 KVAR
P3: - 0.000 KW S3: 0.000 KVA Q3: - 0.000 KVAR
PΣ - 0.000 KW SΣ : 0.000 KVA QΣ : - 0.000 KVAR
PF1: -0.00 PF2: -0.00 PF3: -0.00
PFΣ : 0.00 PFH: 0.00
Φ 1: -0.0° Φ 2: -0.0° Φ 3: -0.0°
WH: 0.000 KWH SH: 0.000 KVAH
QH: 0.000 KVARH FREQ: 0.0 Hz
CP1201 Change
20A 3Φ 4W SEC: 2 CT: 1 PT: 1 Card
B : The bottom right display will show the recorded data
points.
B-1 : Each file can record up to 30,000 data points as
screen 1 when the record points exceed 30,000 points,
system will create a new file automatically. (For example,
WTA01001.XLS will be replaced by WTA01002.XLS)
B-2 : While pressing REC KEY twice, the data logger
function will stop to execute, the record points will
disappear on bottom right display as screen 2.
46
