screen 2 ( 5-3 )
V12: 0.0 V A1: 0.00 A
V23: 0.0 V A2: 0.00 A
V31: 0.0 V A3: 0.00 A
P Σ : - 0.000 KW
S Σ : 0.000 KVA
Q Σ : 0.000 KVAR
PFΣ : 0.00 P F H : 0.00
WH: 0.000 KWH SH: 0.000 KVAH
QH: 0.000 KVARH FREQ: 50.0 Hz
CP1201
20A 3Φ 3W SEC: 2 CT: 1 PT: 1
5-4 3Φ 4W (three phases by four wires)
measurement
A
: Dia
g
ram
screen 1 ( 5-4 )
42
