B: Operation Instructions:
B-1 : Power on the instrument by pressing POWER KEY,
and then press 1Φ 3Φ KEY to select the 3Φ 4W system,
the selected name of system will be appeared on bottom
left display of screen 2.
B-2 : Connect the line voltage L1, L2, L3 and Vn to
V1, V2, V3 and N terminals of the instrument.
B-3 : Place the conductor of CP-1201(A1), CP-1201(A2)、
CP-1201(A3) hook to A1, A2, A3 as screen 1.
B-4 : Connect the outputs of clamp meter
CP-1201(A1), CP-1201(A2), CP-1201(A3) to
A1、A2、A3 terminals of the instrument.
B-5 : The related measuring factors will be appeared
on display, about the instruction of factor please refer
appendix 1 ( 5-12, page 51 ).
screen 2 ( 5-4 )
V12: 0.0 V V1: 0.0 V A1: 0.00 A
V23: 0.0 V V2: 0.0 V A2: 0.00 A
V31: 0.0 V V3: 0.0 V A3: 0.00 A
P1: - 0.000 KW S1: 0.000 KVA Q1: - 0.000 KVAR
P2: - 0.000 KW S2: 0.000 KVA Q2: - 0.000 KVAR
P3: - 0.000 KW S3: 0.000 KVA Q3: - 0.000 KVAR
PΣ - 0.000 KW SΣ : 0.000 KVA QΣ : - 0.000 KVAR
PF1: -0.00 PF2: -0.00 PF3: -0.00
PFΣ : 0.00 PFH: 0.00
Φ 1: -0.0° Φ 2: -0.0° Φ 3: -0.0°
WH: 0.000 KWH SH: 0.000 KVAH
QH: 0.000 KVARH FREQ: 0.0 Hz
CP1201
20A 3Φ 4W SEC: 2 CT: 1 PT: 1
43
