8. Download the saving data from the
SD card to the computer ( EXCEL
software )
1)After execute the Data Logger function, take away the
SD card out from the " SD card socket " ( 3-15, Fig. 1 ).
2)Plug in the SD card into the Computer's SD card slot
( if your computer build in this installation ) or
insert the SD card into the " SD card adapter ". then
connect the " SD card adapter " into the computer.
3)Power ON the computer and run the " EXCEL software ".
Down load the saving data file ( for example the file
name : 3P401001.XLS, 1P201001.XLS, 1P301001.XLS,
3P301001.XLS........) from the SD card to the
computer. The saving data will present into the EXCEL
software screen ( for example as following EXCEL data
screens ) , then user can use those EXCEL data to make
the further Data or Graphic analysis usefully.
EXCEL data screen 1 ( for example )
55
