screen 2 ( 4-5-2 )
Folder Name: WTA01 SETUP
File Name: 3P401001.XLS
REC Date: 2008-11-28 00:03:17
Sampling Time: 2
Delet File: 0 % Decimal: Basic
SD Format: 0 % Clamp Type: CP1201
Use Size: 388 KB A Range: 20A
Free Size: 1946 MB V Range: 200mV
Total Size: 1946 MB RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON Φ1 WH FREQ
Year Month Date Hour Minute Second
2010 12 05 11 15 31
C : File Name description : press or in screen 2 to▲▼
select expect file number from 001 to 050.
Remark : When press or > 2 sec, the setting ▲▼
no. will change fast.
* 1P201001 : 1P2 means one phase by two wires, 01
means folder number, 001 means file number.
* 1P301001: 1P3 means one phase by three wires,
01 means folder number, 001 means file number.
* 3P301001 : 3P3 means three phases by three wires,
01 means folder number, 001 means file number.
* 3P401001 : 3P4 means three phases by four
wires, 01 means folder number, 001 means file
number.
D : The up right display will show " SHIFT1 " symbol
while pressing SHIFT KEY once in screen 2, and then
press to enter next setting function as screen 3▼
( File Name Sampling Time ).→
