Over load ACV 720 ACV rms
protection ACA 1300 ACA with clamp probe
* For the Clamp ,CP-1201
Over Indicator * LCD display show " OL ".
* The data save into the SD card will show
" 9999 " or " 999 "
( overleap the decimal point ).
Under Indicator * LCD display show " UR ".
* The data save into the SD card will show
" 9999 " or " 999 "
( overleap the decimal point ).
Data Hold Freeze the display reading.
Data Record SD Card Record.
Sampling Time Approx. 1 second.
Power ON/OFF Manual OFF by push button.
Real time * Real time data logger, saved the data
data logger into SD memory card and down load
the all the measured value with the
time information ( year/month/data/
hour/minute/second ) down load
to the Excel
* Integration time for data logger :
2 seconds to 7200 seconds, the during
of setting step are 2 seconds.
Data Output RS232 computer serial interface :
USB/RS232 * Connect the optional USB cable
* Computer USB-01 will get the USB plug.
interface * Connect the optional RS232 cable
UPCB-02 will get the RS232
plug.
Operating 0 to 50 ( 32 to 122 ).℃℉
Temperature
Operating Less than 80% R.H..
Humidity
Power Supply * DC 1.5V, AA ( UM-3 ) Battery X 8 PCs
(Alkaline or heavy-duty battery).
* AC to DC 9V power adapter.
