4)Screw the " Probe head " ( 7-3, Fig 5 )
into the probe body.
Fig. 5
5
)
When not use the
probe, should insert
the " Probe head "
into the " Probe 7-1 Probe handle
protection cover " 7-2 Temp. sensing metal
( 6-5, Fig. 4 ) 7-3 Probe head
8. DATA HOLD, DATA RECORD,
DATA LOGGER,
LCD BACKLIGHT
8-1 Data Hold
During the measurement, press the " Hold Button " ( 3-3,
Fig. 1 ) once will hold the measured value & the LCD will
display a " HOLD " symbol.
Press the " Hold Button " once again will release the data
hold function.
8-2 Data Record ( MAX, MIN reading )
* The data record function records the maximum and
minimum readings. Press the " REC Button " ( 3-4, Fig.
1 ) once to start the Data Record function and there
will be a " REC " symbol on the display.
* With the " REC " symbol on the display :
a)Press the " REC Button " ( 3-4, Fig. 1 ) once, the
" REC MAX " symbol along with the maximum value
will appear on the display.
If intend to delete the maximum value, just press
the " Hold Button " ( 3-3, Fig. 1 ) once, then the
display will show the " REC " symbol only & execute
the memory function continuously.
