2) After set all the time value ( Year, Month, Date, Hour,
Minute, Second ), press the " Enter Button " ( 3-8, Fig.
1 ) once will save the time value, then the screen will
jump to " Sampling time " setting screen ( Chapter 12-3 ).
Remark :
After the time value is setting, the internal clock will
run precisely even Power off if the battery is under
normal condition ( No low battery power ).
12-3 Set sampling time ( Second )
When the " SAMPLE TIME " text is yellow color
1)
Press "Enter" into the setting function,then use the "
Button
" ( 3-5, Fig. 1 ) or "
Button " ( 3-6, Fig. 1 ) to adjust the
value ( Setting start from value )1,2,5,10,30,60,120,180,300,
600,1800,3600 Sec., After the desired value is set, press
the" Enter Button " ( 3-4, Fig. 1 ) once will save the sampling
value with default then the screen will jump to
" Auto power OFF " setting screen ( Chapter 12-4 ).
Remark :
The adjusted value will be flashed.
41
