Luvion prestige touch 2 - Baby Unit Overview

26
23. DC in Connect the included DC 5V power adapter to power and/or charge the parent unit.
24. On/O button Turns the parent unit ON or OFF.
OVERVIEW OF BABY UNIT CAMERA
LUVION
BACK VIEWFRONT VIEW
2
3
6
4
5
7
8
1. Temperature sensor The measured ambient temperature is displayed on the screen of the parent unit.
2. Light Sensor Allows the baby unit to correct itself under changing light conditions.
3. Camera lens Detects the visual environment and sends this to the parent unit.
4. Microphone Detects sound and sends this to the parent unit.
5. Speaker Enables the ability to talk to your child over distance.
6. IR LED’s Allows for 5m distance of night vision, automatically activates within low lights conditions.
1
