TECHNICAL SPECIFICATIONS
General Speci cations
Operating Frequency Range 2.400 MHz ~ 2.483,5 MHz
Transmitting Power 15 dBm Max
Receiving Sensitivity -81 dBm
Type of Spread Spectrum FHSS 39 Channels
Type of Modulation GSFK
Data Rate 4 Mbps
Transmitting Distance 300 m (Line of Sight)
Baby unit (camera)
Image Sensor Type 1/4” OV7725 Color CMOS Image Sensor
E ective Pixels H: 640 px, V: 480 px
Image Resolution/Frame Rate 20 fps
White Balance Auto
Lens 4.5 mm, F 1.5
Field of View 60°
IR On/O 15-25 Lux O , 5-15 Lux On
IR LED Type/Nacht Vision 850 nm / 5 m
Speaker Output 0.5 W Max
Power Requirement 5 Vdc +/- 10%
Power Consumption 600mA+/-20mA
Operating Temperature Range - 10° ~ 40°
Operating Humidity Range 80% HR
Environment Rating N/A (for indoor use only)
Dimensions 85 x 105 x 112mm
Regulation Compliance FCC/CE
Camera Housing Material Plastic
Motory Type Stepping motor
Moving Angle Up 90° Down 20° Left/Right 135°
