7
12. Output mode selection button
(OUTPUT MODE)
Switches between three output modes; unbalanced output,
balanced output and bi-amp output. Every time this button
is pressed, the phase changes as follows: UNBAL →
BAL → BI-AMP → UNBAL → ...
• Unbalanced output (UNBAL)
Outputs audio from LINE-1 and LINE-2.
• Balanced output (BAL)
Outputs audio from BAL LINE-1 and BAL LINE-2.
• Bi-amp output (BI-AMP)
Outputs audio from LINE-1 and LINE-2.
LINE-1 (Lch): LOW (Lch)
LINE-1 (Rch): LOW (Rch)
LINE-2 (Lch): HIGH (Lch)
LINE-2 (Rch): HIGH (Rch)
When BAL is selected by the input selector, switching to
BI-AMP is unavailable.
To switch to BI-AMP, switch the input selector to UNBAL
first and then switch to BI-AMP.
Factory default: Unbalanced output (UNBAL)
While switching the output mode, the input/output muting
circuit is activated and no sound is generated.
The preset setting values are stored for each output mode.
Refer to how to make preset on pages 22 through 27 for
further information on preset.
