INTEGRATED AMPLIFIER L-590AX
9
5. Standby indicator (STAND BY)
Lights up when the AC plug is plugged into a wall socket
and the operation switch is set to off.
This indicator turns off when the AC plug is disconnected
from the wall socket or the power switch is set to on. This
indicator blinks when the protection circuit is activated.
6. Remote sensor (REMOTE)
Receives signals from the accessory remote control.
7. Loudness indicator (LOUDNESS)
Lights up when the loudness switch is on.
8. Line straight indicator (LINE STRAIGHT)
Lights up when the line straight switch is on.
When the line straight switch is set to on, the subsonic,
monaural and loudness cannot be adjusted from the
accessory remote control.
When one of these switches is pressed, the line straight
indicator blinks for 3 seconds to show that this unit cannot
be operated.
Adjust the subsonic, monaural or loudness after setting the
line straight switch to off.
9. Separate indicator (SEPARATE)
Lights up when the separate switch is on.
The subsonic, monaural and loudness can be toggled only
from the accessory remote control (RA-17).

Luxman L-590AX Specifications

General

Type	Integrated Amplifier
Output Power	30W + 30W (8Ω), 60W + 60W (4Ω)
Input Impedance	47kΩ (LINE)
Frequency Response	20Hz-20kHz (+0, -0.5dB)
Signal-to-Noise Ratio	105dB (LINE)
Dimensions	440 x 193 x 463 mm
