13
How to connect power supply
Use the accessory power cable and insert the AC plug in an
outlet on the wall in the room where the unit will be installed.
How to connect CD player, SACD player,
tuner, or other devices
Connect between the output terminals of a CD player, an
SACD player, a tuner, or other such input devices and the
LINE-1 input terminals of this unit with 2 (R and L) pin-plug
cables or balanced cables.
For LINE-2, LINE-3, and LINE-4 input terminals, connection
in the same fashion as the LINE-1 terminals provides the
reproduction likewise.
How to connect speakers
Connect the left-channel speaker to the LEFT SPEAKER
terminal of this unit and the right-channel speaker to the
RIGHT SPEAKER terminal.
Securely connect the ! terminal of the speaker system to
the speaker terminal ! (red) of this unit, and the @ terminal
of the speaker system to the speaker terminal @ (black) of
this unit.
If the ! and @ terminals are reversely connected to either
of the right and left speaker systems, the acoustic phases
of the sound reproduced from the right and left speaker
systems are also reversed. In such a case, be aware that
the sound level in the low range will be reduced and the
acoustic stability will worsen, thus failing in normal stereo
playback.
