Analog Values
Object
Instance
Description Default value
Tags
Minimum
range value
Maximum
range value
Object name
AV43
USsupplyT Upstream supply T° (from main fan)
---
Status
32°F (0°C) 122°F (50°C)
AV44
DSsupplyT
Downstream supply T° (after reheat)
---
Status
32°F (0°C) 122°F (50°C)
AV46
AuxA_Out Auxiliary output A
---
Status
0% 100%
AV47
AuxB_Out Auxiliary output B
---
Status
0% 100%
AV48
AuxC_Out Auxiliary output C
---
Status
0% 100%
AV49
AuxD_Out Auxiliary output D, (Tzone #2)
---
Status
0% 100%
AV50
AuxE_Out Auxiliary output E, (Tzone #3)
---
Status
0% 100%
AV52
EncodedVal1 Internal Use
---
Status
--- ---
AV53
EncodedVal2 Internal Use
---
Status
--- ---
AV55
ActiveTz2SPHtg Active heating Tzone #2 setpoint
--- User AV10 AV11
AV56
ActiveTz2SPClg Active cooling Tzone #2 setpoint
--- User AV10 AV11
AV57
ActiveTz3SPHtg Active heating Tzone #3 setpoint
--- User AV10 AV11
AV58
ActiveTz3SPClg Active cooling Tzone #3 setpoint
--- User AV10 AV11
AV64
RoomRH Room relative humidity
---
Status 0% 100%
AV65 RoomCO2 Room carbin dioxide (CO2)
---
Status 0PPM 2000PPM
Please note that objects tagged as:
• Cfg: represent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
