Lynxspring ONYXX LX BZ424-LX User Manual

Multi-State Values
Object
Instance
FCU
Object name
Description
Tags
Default value State texts
MSV9
AuxB_Type Auxiliary output B control type
Cfg
Elect. Bboard
None
Elect. Reheat
Water Reheat
Elect. Bboard
Water Bboard
DX Cool
Water Cool
MSV10
AuxB_Formula Auxiliary output B formula Cfg Pulse, Dir.
0-10 VDC, Dir.
0-10 VDC, Rev.
2-10 VDC, Dir.
2-10 VDC, Rev
On-Off
Pulse, Dir.
Pulse, Rev.
MSV11 AuxB_Auto Auxiliary output B authorization
Cfg
Always
Never
Always
FanStatus
MaxPower
Fan+MaxPwr
Please note that objects tagged as:
• Cfg: represent configuration properties of the device that are typically only set once during commissioning and start-up
• User: represent properties or objects that are typically manipulated by users of the controller
• Status: represent objects or properties that are ‘’typically’’ meant to be displayed on graphics for various required visualization
• Cmd: represent objects that can be controlled directly by other BACnet external process
