MacDon M150 - Windrower Controls

OPERATOR’S STATION
Form 169017 / 169087 / 169095 28 Revision C
5.16 WINDROWER CONTROLS
AUTO-STEER ENGAGEMENT SWITCH
Engages Auto-Steer System (If compatible system is installed).
ENGAGE - Click To Engage.
DISENGAGE - Turn Steering Wheel To Disengage.
HAZARD WARNING LIGHTS
Activates Signals On Windrower Tractor and Header
Momentary Switch On Monitor
FAST
SLOW
GROUND SPEED LEVER (GSL)
Controls Speed and Direction of Movement
F - Forward
N - Neutral
N-DETENT - Engages Neutral Interlock and Applies
Park Brake When Steering Locked In Center
R - Reverse
GROUND SPEED RANGE SWITCH
Shifts Transmission Speed Range
H - 0 - 23 mph (37 km/h). ENGINE-FORWARD ONLY.
- 0 -16 mph (25.7 km/h). CAB-FORWARD ONLY.
L - 0 -11 mph (17.7 km/h)
N-DETENT
TURN SIGNALS
Activates Turn Signals On Windrower and Header
Momentary Switches On Monitor
REVERSE
