5.18.6 SETTING GUIDELINES
5.18.6.1 Pressure Settings
WINDROWER
MODEL
HEADER MODEL APPLICATION/SYSTEM
SUGGESTED OVERLOAD
WARNING SETTING
psi (kPa)
WINDROWER
PRESSURE COMP
SETTING
psi (kPa)
M150 D60 and A40D Reel / Draper Pressure 3000 (20684) 3200 (22063)
M150 D60 and A40D Knife / Conditioner Pressure 4000 (27579) 4200 (28958)
M150 R80 Disc Pressure 4000 (27579) 4200 (28958)
M200 R80 Disc Pressure 4300 (29647) 4500 (31026)
M200 D60 and A40D Reel / Draper Pressure 3000 (20684) 3200 (22063)
M200 D60 and A40D Knife / Conditioner Pressure 4300 (29647) 4500 (31026)
5.18.6.2 R Series Rotary Header Disc Speeds
CROP CONDITION DISC RPM *
Alfalfa
Heavy 2100 - 2300
Light 1800 - 2000
Sudan, Sorghum,
Haygrazer,
Timothy
Tall and
Stemmy
2300 - 2500
Short Grass
Dense 2500
Thin 2000 - 2200
*Suggested Overload Setting - 1300 rpm.
5.18.6.3 Engine Error Codes
The CDM displays “Error Codes” when there is a
fault with one of the several sensors that monitor
and control engine operation, to assist the
operator or technician in locating a specific
problem with engine operation.
Refer to the Appendix for the “Error Codes”.
5.18.7 CDM AND WCM FAULT CODES
The CDM displays “Fault Codes” when there is a
fault with one of the several sensors that monitor
and control windrower operation, to assist the
operator or technician in locating a specific
problem with the windrower.
Refer to the Appendix for the “Fault Codes”.
