OPERATOR’S STATION
Form 169017 / 169087 / 169095 36 Revision C
CAB - FORWARD / ENGINE RUNNING / HEADER ENGAGED
AUGER HEADER
(Scroll Through Display with CDM Switch or GSL Switch)
DISPLAY (Lower or Upper Line) DESCRIPTION
#####.# ENGINE HRS
Total Engine Operating Time.
#####.# HEADER HRS
Total Header Operating Time.
##.# ACRES/HOUR
##.# HECTARES/HOUR (If Metric)
Actual Cutting Rate In Acres (Hectares) / Hour.
###.# SUB ACRES
###.# SUB HECTARES (If Metric)
Area Cut Since Last Reset.
To Reset, Display SUB ACRES On Lower Line And
Hold Down Program Switch Until Display Resets
(5 - 7 Seconds).
###### TOTAL ACRES
###### TOTAL HECT (If Metric)
Total Area Cut By Machine.
##.## REEL RPM
##.## REEL SENSOR (If Sensor Disabled)
Reel Rotational Speed.
##.# AUGER SPEED
Auger Rotational Speed (4.7 - 9.9).
#### KNIFE SPEED
#### KNIFE SENSOR (If Sensor Disabled)
Knife Speed In Strokes Per Minute.
##.# HEADER HEIGHT
##.# HEIGHT SENSOR (If Sensor Disabled)
Distance Setting (00.0 - 10.0) Between Cutterbar and
Ground.
##.# HEADER ANGLE
##.# TILT SENSOR (If Sensor Disabled)
Angle Setting (00.0 - 10.0) Header Relative To Ground.
##.# L FLOAT R ##.#
FLOAT SENS DISABLED (If Sensor Disabled)
Left And Right Float Setting (0.0 - 10.0).
LOAD|■■■■■_____| ####
(If Metric) #####
Bar Graph Representing Hydraulic Operating Pressure.
Full Scale Is Pre-Programmed Overload Pressure
(M150: 2500 - 4000 PSI; M200: 2500 - 4800 PSI).
If Sensor Disabled, LOAD Does Not Display. See Note.
##.# VOLTS
Engine Electrical System Operating Voltage.
SCROLL
SUB-MENU (Lower Line Only)
#### KNIFE SPEED
##.# HEADER HEIGHT
LOAD|■■■■■■■■■■■■| ####
Displays Sub-Menu After 2 - 3 Seconds.
Press SELECT to cancel.
Scroll Through Sub-Menu Display with CDM Switch
NOTE: The LOAD sensor is factory installed on M200 (optional for M150) to monitor knife/conditioner circuit pressure.
To monitor reel circuit pressure, relocate sensor as per Instructional Manual #169031 which is available through your MacDon
Dealer.
