OPERATOR’S STATION
Form 169017 / 169087 / 169095 40 Revision C
MISCELLANEOUS OPERATIONAL INFORMATION
DISPLAY (Upper Line) DESCRIPTION
< LEFT TURN ■
Indicates Left Turn When Is Pressed On
CDM. See Note 1.
■ RIGHT TURN >
Indicates Left Turn When Is Pressed On
CDM. See Note 2.
■ HAZARD ■
Indicates Hazard Warning Lights Are On When
Is Pressed On CDM.
HEADER REVERSE
Header Drive Running In Reverse.
HEADER ENGAGED
Header Drive Engaged.
ROAD GEAR
With Hi Range Selected On Console Switch.
Engine-Forward Only. See Note.
NOTE: 1. If road light kit is not installed, CDM will display LEFT STOP LAMP as a malfunction.
2. If road light kit is not installed, CDM will display RIGHT STOP LAMP as a malfunction.
