20
Item# Part # Description Rev Qty
Master Parts List 090-078-00 M2600 Assembly, 120v
1 040-257-00 CBL ASSY 24GA 3P .098 6IN B 1
2 040-272-00 DIS 14G 1010 BRN 7.5 QDX2 B 1
3 040-273-00 DIS 14G 1010 BLU 6.5 QDX2 A 1
5 040-301-00 CBL ASSY SW PWR 23IN A 1
6 055-131-00-01 PCB ASSY INPUT - 2600 A 1
7 055-132-00-01 PCB ASSY DISPLAY M2600 A2 1
8 055-133-00-01 PCB ASSY PWR DIST 120V A1 1
9 055-171-00-01 PCB ASSY PWR SPLY M2600 A 1
10 055-172-00-01 PCB ASSY SPKR OUTPUT 2600 A 1
11 080-076-00 SA AMP M2600 A6 1
12 080-087-10 SA HANDLE RIGHT M2600 A 1
13 080-087-20 SA HANDLE LEFT M2600 A 1
080-115-00 ASSY WIRE RCPT GND A 1
23 080-117-00 SA XFMR M2600 120V A 1
400-331-00 INSERT JACK BAN M-MAN RED A AR
400-332-00 INSERT JACK BAN M-MAN BLK A AR
15 500-022-00 SW RCKR ILLUMINATED A 1
510-044-00 FUSE SB 30A 3AB A 1
16 550-245-00 SCRN CHASSIS M2600 B 1
17 550-246-00 PNT SIDE RAIL RT- M2600 A 1
18 550-370-00 BRKT BRIDGE RECT HEATSINK A 1
19 550-371-00 BRKT XFMR MOUNT M2600 A 1 (transformer bracket)
20 550-376-00 PNT COVER TOP M2600 A 1
21 550-378-00 PNT SIDE RAIL LT - M2600 A 1
46 550-419-00 FAB BRKT CBLE SHLD M2600 A 1
22 551-029-40 EXTR SCRN DSPLY BZL-M2600 C 1
49 640-009-00 LC IEC SJT 20A/125V 12AWG A 1
31 700-005-00 SEMS 8-32X1/2 PHP BLKZC A 2
24 700-011-00 MCH 4-40X1/4 BTNSKT BLKOX A 8
25 700-027-00 SEMS 8-32X3/8 PHP BLKZC A 24
26 700-028-00 SEMS 6-32X1/4 PHP BLKZC B 13
27 700-041-04 MCH 6-32X3/8 FL 100DG BLK A 7
30 700-085-03 SCR PHP M3X6 STL BLK ZC A 4
32 700-091-00 SEMS 8-32X3/4 PHP BLKZC A 6
34 700-094-04 MCH 4-40X3/8 82DEG FL BLK A 2
35 700-096-00 BOLT HEX 5/16X3-3/4 GR5 Z A 1 (transformer bolt)
33 700-097-00 MCH 8-32X1/4 FL 82DG UCUT A 4
29 701-016-00 5-20X5/16 PHPII TYP B BLK A 14
36 705-001-00 KEPNUT 6-32 A 4
37 705-003-00 NUT HEX-SPLD W/400-214-00 A AR
38 705-008-00 NUT LOCK 8-32 A 2
39 705-019-00 NUT STOVER LOCK 5/16X18 A 1 (transformer nut)
40 710-002-00 WASHER-SPLD W/400-214-00 A AR
41 710-024-00 WASH FLAT 5/16 HARD (USS) A 1 (transformer bottom washer)
47 710-034-00 WASH STL .063X.344X.688 A 1 (transformer top washer)
48 730-001-00 THERMAL JOINT COMPOUND A AR
49 740-003-00 TYRAP 8IN BLK A 4
42 710-032-00 WASH SHLD FIBRE .317X.750 A 1 (transformer shoulder washer)
53 720-007-00 TAPE DS 30MIL X 1.0W URTH A AR
730-016-00 LOCTITE 242 A AR
750-001-00 BUMPON ROUND BLK .63X.31 A 4
43 760-048-01 KNOB 9MM LT GRY B 2
44 760-061-00 KNOB VOLUME AMPS A 2
45 780-111-00 WASH RUB (W/TRANSFORMER) A 2 (transformer insulator washers)
790-002-00 BAG POLY 12 X 18 2MIL A 1
NOTE:The Item numbers in
the first column of this page
refer to the Final Assemby
Drawings on pages 14-16
