055-130-00 Rev A Channel 2 board
Part # Description Value Reference Designator
040-262-00 RIB 28GA TRAN 40C 3IN J3
040-269-00 DIS 14GA RED 6 IN QDX2 J5
040-270-00 DIS 14GA BLKRED 6IN QDX2 J6
121-077-00 RESISTOR MOF 150 5% R60
123-013-00 RESISTOR MOF 0.33 5% R40-55
123-045-00 RESISTOR MOF 6.8 5% R61-69
123-056-00 RESISTOR MOF 20 5% R70
123-125-00 RES MO 3W 5% 15K OHM 15K 5% R58-59 R73-74
150-009-00 RESISTOR, FUSABLE, 1/4W 2.2 5% R2 R4 R7 R9 R11 R15 R17 R19 R22 R24 R27
R29 R32 R34-35 R37
150-037-00 RES FUS .25W 5% 33 OHM 33 5% R1 R3 R5 R8 R10 R12-14 R16 R18 R20 R23
R25 R28 R30 R33 R36 R38 R56-57
150-045-00 RES FUS .25W 5% 68 OHM 68 5% R6 R21 R26 R31 R39 R71
150-066-00 RESISTOR, FUSABLE, 1/4W 510 5% R75
200-036-02 CAP, METALIZED POLY, T/R .1uF 10% C21 C26
200-041-00 CAPACITOR POLY HI-CURRENT 0.01 10% C25
205-003-02 MICA 330PF 5% 500V 330pF 5% C29-30
211-003-00 CER .001UF 10% 50V AX 0.001 10% C1
211-009-00 CAPACITOR CERAMIC AXIAL 0.1 10% C7 C9 C11 C13 C15 C17
220-011-02 CAPACITOR LYTIC RADIAL T&R 100UF 10% C14 C16 C18 C20
220-027-02 CAPACITOR LYTIC RADIAL T&R 10UF 10% C23-24
220-047-00 LYT 47UF 20% 160V RAD 47UF 20% C19 C22
301-009-00 DIODE POWER 1N4004 D4
301-010-00 DIODE POWER 1N5404 D1-2
302-003-00 DIODE ZENER 1N4745 D3 D5
310-033-00 TRANSISTOR PNP MJL21193 Q15-16 Q18-19 Q21-24
310-034-00 TRANSISTOR NPN MJL21194 Q2-3 Q6-7 Q9-10 Q12-13
310-042-00 TRANSISTOR NPN MJE15032 Q1 Q5 Q8 Q11
310-043-00 TRANSISTOR PNP MJE15033 Q14 Q17 Q20 Q25
310-049-00 XSTR PNP 2SA794A 2SA794A Q29
310-050-00 XSTR NPN 2SC1567A 2SC1567A Q4 Q28
310-055-00 XSTR NPN 2SA1480 2SA1480 Q27
310-056-00 XSTR PNP 2SC3790 2SC3790 Q26
400-077-00 HEADER STR LCK SHRD 20P .100 X 2 J2
400-129-00 FUSE CLIP 0.25 DIA PC MNT Z1-3 Z5
400-173-00 CONN QUICK DISC .250 J4
W/STABLE-LOK TABS
400-231-00 HEADER, 2X5, MATE-N-LOCK J1
450-130-00 PCB M2600 CH-2 AMP Z4
490-021-00 MAGNET .200 THK X .50 DIA Z6
501-003-00 RELAY, SPDT T9AS5D12-24 K1
510-041-00 FUSE 25A FB 3AG 25A F1-2
601-006-00 INDUCTOR, AIR CORE 1uH 10% L1
601-008-00 INDUCTOR 10uH L2-3
706-033-05 STANDOFF, SWAGE, 4-40 X .312L H1-4 H6
Components noted with this symbol shall be replaced only by the component
specified.This is required to maintain product safety.
