Mackie M2600 - 055-186-00 Rev a 15 Volt Supply;Fan Drive Board

30
055-186-00 Rev A 15 Volt supply/fan drive board
Part # Description Value Reference Designator
TEST POINT, PART OF PCB J1-2
100-031-00 RESISTOR CF 180 5% R8
100-049-00 RESISTOR CF 1K 5% R7
100-056-00 RESISTOR CF 2K 5% R10
100-061-00 RESISTOR CF 3K3 5% R6
100-066-00 RESISTOR CF 5K1 5% R2
100-068-00 RES CF .125W 5% 6K2 OHM 6K2 5% R5
100-069-00 RESISTOR CF 6K8 5% R4
100-073-00 RESISTOR CF 10K 5% R9
100-078-00 RESISTOR CF 16K 5% R3
100-080-00 RESISTOR CF 20K 5% R13
100-090-00 RES CF .125W 5% 51K OHM 51K 5% R12
100-097-00 RESISTOR CF 100K 5% R11
121-081-00 RESISTOR MF 2K2 5% R14
130-021-00 RESISTOR POT TRIM HORIZ 10KB R1
211-009-00 CAPACITOR CERAMIC AXIAL 0.1 10% C3 C5 C7-8
220-001-02 CAPACITOR LYTIC RADIAL T&R 22UF 10% C2 C4 C9
220-027-02 CAPACITOR LYTIC RADIAL T&R 10UF 10% C1 C6
300-001-00 DIODE SIGNAL 1N4148 D5-7
301-009-00 DIODE POWER 1N4004 D1-4
310-002-00 TRANSISTOR PNP 2N4403 Q3
310-024-00 TRANSISTOR PNP 2SB817 Q1
310-050-00 TRANSISTOR NPN 2SC1567A Q2
320-011-00 I.C. LINEAR NJM 4560 U3
321-001-00 I.C. LINEAR NEG 3 TERM VOLTAGE LM 7915 U1
REGULATOR
321-002-00 I.C. LINEAR POS 3 TERM VOLTAGE LM 7815 U2
REGULATOR
400-078-00 CONNECTOR STR LCK SHRD 10P .100 X 2 J4
400-171-00 CONN, HDR, 2-PIN, UN-SHROUDED, 0 .100 J3
450-186-00 PCB, M2600, +/-15V SUPPLY & FAN DRIVE Z1
550-369-00 BRACKET, L H1-2
601-013-00 CHOKE, POWER AXIAL 470uH L1-2
712-021-01 RIVET Z4-7
