29
055-172-00-01 Rev A Speaker output board
Part # Description Value Reference Designator
400-138-01 SPEAKONS HORIZ 4 CKT J2-4
400-173-00 CONN QUICK DISC .250 W/STABLE-LOK TABS J5-8
400-237-00 CONNECTOR, QUAD BANANA J1
450-172-00 PCB, M2600, OUTPUT Z1
055-171-00-01 Rev A Power supply board
Part # Description Value Reference Designator
100-077-00 RES CF .125W 5% 15K OHM 15K 5% R10-12
123-109-00 RESISTOR MOF 3.3K 5% R1-8
150-037-00 RESISTOR, FUSABLE, 1/4W 33 5% R9
200-036-02 CAP, METALIZED POLY, T/R .1uF 10% C15-22
211-009-00 CAPACITOR CERAMIC AXIAL 0.1 10% C23-24
220-006-00 CAPACITOR LYTIC RADIAL 2200UF 10% C9-12
220-029-00 CAPACITOR LYTIC RADIAL 2200UF 20% C13-14
220-041-00 CAPACITOR LYTIC RADIAL 15,000uF20% C1-8
300-001-00 DIO SIG 1N4148 100V 500MW 1N4148 D19-20
301-009-00 DIODE POWER 1N4004 D1-5 D10-16
301-010-00 DIODE POWER 1N5404 D6-9
301-015-00 DIODE BRIDGE 25A D17-18
310-007-00 XSTR NPN 2N4401 2N4401 Q1
400-060-00 FUSE CLIP PCMT 5MM DIA Z1-3 Z5
400-133-00 HEADER, 2X3, MATE-N-LOCK J6
400-173-00 CONN QUICK DISC .250 J3-5
W/STABLE-LOK TABS
400-231-00 HEADER, 2X5, MATE-N-LOCK J1-2
450-171-00 PCB, M2600, POWER SUPPLY Z4
510-026-00 FUSE 5X20 T-3.15A F1-2
Components noted with this symbol shall be replaced only by the component
specified.This is required to maintain product safety.
