22
055-129-00 Rev A Channel 1 board
Part # Description Value Reference Designator
040-261-00 RIB 28GA TRAN 10C .1 3IN J1
040-262-00 RIB 28GA TRAN 40C 3IN J6
040-265-00 DIS 14GA BLK/ WHT 4.5IN QD J4
040-266-00 DIS 14GA BLK/ WHT 6IN QDX2 J12
040-267-00 DIS 14GA WHT 6IN QDX2 J8
040-268-00 DIS 14GA BLKWHT 6IN QDX2 J9
121-077-00 RESISTOR MOF 150 5% R58
123-013-00 RESISTOR MOF 0.33 5% R40-55
123-045-00 RESISTOR MOF 6.8 5% R60-68
123-056-00 RESISTOR MOF 20 5% R59
123-125-00 RES MO 3W 5% 15K OHM 15K 5% R70-73
150-009-00 RES FUS .25W 5% 2.2 OHM 2.2 5% R3 R5-6 R8 R11 R13 R16 R18 R21 R23 R25
R29 R31 R33 R36 R38
150-037-00 RES FUS .25W 5% 33 OHM 33 5% R1 R4 R7 R9 R12 R14 R17 R19 R22 R24
R26-28 R30 R32 R34 R37 R39 R57 R69
150-045-00 RES FUS .25W 5% 68 OHM 68 5% R2 R10 R15 R20 R35 R56
150-066-00 RESISTOR, FUSABLE, 1/4W 510 5% R75
200-036-02 CAP, METALIZED POLY, T/R .1uF 10% C22 C27
200-041-00 CAPACITOR POLY HI-CURRENT 0.01 10% C24
205-003-02 MICA 330PF 5% 500V 330pF 5% C30-31
211-003-00 CER .001UF 10% 50V AX 0.001 10% C1
211-009-00 CAPACITOR CERAMIC AXIAL 0.1 10% C2 C4 C6 C8 C15 C17
220-011-02 CAPACITOR LYTIC RADIAL T&R 100UF 10% C14 C16 C18 C20
220-025-00 CAPACITOR LYTIC RADIAL 1,000UF10% C21
220-027-02 CAPACITOR LYTIC RADIAL T&R 10UF 10% C25-26
220-047-00 LYT 47UF 20% 160V RAD 47UF 20% C19 C23
301-009-00 DIODE POWER 1N4004 D5
301-010-00 DIODE POWER 1N5404 D1-2
302-003-00 DIODE ZENER 1N4745 D3-4
310-033-00 TRANSISTOR PNP MJL21193 Q13-14 Q16-17 Q19-20 Q23-24
310-034-00 TRANSISTOR NPN MJL21194 Q2-5 Q7-8 Q10-11
310-042-00 TRANSISTOR NPN MJE15032 Q1 Q6 Q9 Q12
310-043-00 TRANSISTOR PNP MJE15033 Q15 Q18 Q21 Q25
310-049-00 XSTR PNP 2SA794A 2SA794A Q29
310-050-00 XSTR NPN 2SC1567A 2SC1567A Q22 Q28
310-055-00 XSTR NPN 2SA1480 2SA1480 Q27
310-056-00 XSTR PNP 2SC3790 2SC3790 Q26
400-077-00 HEADER STR LCK SHRD 20P .100 X 2 J5
400-129-00 FUSE CLIP 0.25 DIA PC MNT Z1-4
400-231-00 HEADER, 2X5, MATE-N-LOCK J2
400-242-00 CONNECTOR,STR,3P,.098 X 1,SHRD J3
400-243-00 CONNECTOR,STR,2P,.098 X 1,SHRD J7
450-129-00 PCB, M2600 CH-1 AMP Z5
490-021-00 MAGNET, .2THK .5DIA Z6
501-003-00 RELAY, SPDT T9AS5D12-24 K1
510-041-00 FUSE 25A FB 3AG 25A F1-2
601-006-00 INDUCTOR, AIR CORE 1uH 10% L1
601-008-00 INDUCTOR 10uH L2-3
Components noted with this symbol shall be replaced only by the component
specified.This is required to maintain product safety.
