Mackie M2600 - 055-133-00-01 Rev a Power Distribution 120 V

26
055-133-00-01 Rev A Power distribution 120V
Part # Description Value Reference Designator
040-137-00 DIS 18GA GN/YL 96IN QD LUG J11
121-077-00 RESISTOR MOF 150 5% R3
125-020-00 RESISTOR WIRE WOUND 82 5% R1-2
200-023-00 CAPACITOR, POLY BOX .001uF 20% C1-2
200-024-00 CAPACITOR, POLY BOX .01uF 20% C3-4
301-009-00 DIODE POWER 1N4004 D1
400-129-00 FUSE CLIP 0.25 DIA PC MNT Z1-2
400-173-00 CONN QUICK DISC .250 J1-10 J12-15
400-173-00 CONN QUICK DISC .250 J16-17
-00 AND -02 ASSY ONLY
400-173-00 CONN QUICK DISC .250 J18
-01 ASSY ONLY
400-242-00 CONNECTOR,STR,3P,.098 X 1,SHRD J23
450-133-00 PCB, M2600 PWR DISTRO & AC-INRUSH Z3
501-003-00 RELAY, SPDT T9AS5D12-24 RL1
510-017-00 FUSE 20A SLO-BLO -02 ASSY ONLY F1 Z4 (100 VOLT MODELS ONLY)
510-018-00 FUSE 15A SLO-BLO -01 ASSY ONLY F1 Z6 (240 VOLT MODELS ONLY)
510-033-00 FUSE 25A SLO-BLO -00 ASSY ONLY F1 Z5 (120 VOLT MODELS ONLY)
Components noted with this symbol shall be replaced only by the component
specified.This is required to maintain product safety.
