Mackie M2600 - 055-131-00-01 Rev a Input Board

24
055-131-00-01 Rev A Input board
Part # Description Value Reference Designator
DO NOT STUFF C22 C24
040-258-00 RIB 28GA TRAN 20C .1 5IN J6
040-259-00 RIB 28GA TRAN 20C .1 6IN J5
040-260-00 RIB 28GA TRAN 20C .1 20IN J11
100-027-00 RESISTOR CF 120 5% R23 R28-29 R50-51 R65
130-062-02 RES POT 12MM HORIZ DUAL 50KC R11 R66
140-078-00 RESISTOR TF SMT 1K6 5% R7 R67
140-082-00 RES TF SM .1W 5% 2K4 OHM 2K4 5% R9 R69
140-089-00 RESISTOR CF 4K7 5% R24-27 R52-53
140-090-00 RES TF SM .1W 5% 5K1 OHM 5K1 5% R80-81
140-095-00 RES TF SM .1W 5% 8K2 OHM 8K2 5% R8 R68
140-123-00 RES TF SM .1W 5% 100K OHM 100K 5% R77-79
145-318-00 RESISTOR MF SMT 2K00 1% R4 R6 R38-41 R72 R74
145-331-00 RESISTOR MF SMT 2K49 1% R35 R59
145-346-00 RESISTOR MF SMT 3K57 1% R14 R17 R44 R47
145-389-00 RESISTOR MF 10K0 1% R3 R5 R21-22 R32 R56 R63-64 R71 R73
145-397-00 RESISTOR MF 12K1 1% R1-2 R12-13 R16 R18 R30-31 R36-37
R42-43 R46 R48 R54-55 R60-61 R75-76
145-406-00 RESISTOR MF SMT 15K0 1% R20 R62
145-426-00 RESISTOR MF SMT 24K3 1% R15 R19 R33-34 R45 R49 R57-58
200-025-02 CAPACITOR MYLAR T&R 0.56 C10-11 C38-39
200-029-02 CAPACITOR MYLAR T&R 0.22 C12-13 C20-21 C28-29 C36-37
212-001-00 CAPACITOR CERAMIC SMT 0.01 10% C4-5 C14-19 C23 C25 C30-35 C41-42
212-004-00 CAPACITOR CERAMIC SMT 220PF 5% C3 C6-7 C40 C43-44
212-009-00 CAPACITOR CERAMIC SMT 47PF 5% C1-2 C45-46
220-001-02 CAPACITOR LYTIC RADIAL T&R 22UF 10% C8-9 C26-27 C47-48
300-003-00 DIODE SIGNAL SMD DL4148 D1-6 D9-16
302-002-03 4.7V DL5230B D7-8
320-006-00 OPAMP 2068E NJM 2068 U1 U11
320-012-00 OPAMP NJM4560M NJM4560M U2-4 U6 U8-10
329-012-00 OPTO-ISOLATOR,LED/CDS VTL5C10 U5 U7
400-041-00 CONNECTOR XLR PC MTG VERT MALE J7 J10
400-214-00 CONNECTOR JACK 1/4” VERT PC J3 J12
MOUNT W/1MM LW
400-223-00 CONNECTOR XLR PC MTG VERT FML J4 J13
400-269-00 TERM QDISC RTA .250 PCMT J1
450-131-00 PCB, M-2600 INPUT Z1
500-023-00 SWITCH 4P3T SW1-6
706-013-00 STDF NO.4 X .978L M/F H1-2
