Mackie M2600 - Page 28

28
055-170-00 Rev A, continued
Part # Description Value Reference Designator
200-011-02 CAPACITOR MYLAR T&R 0.0022 5% C59
200-036-02 CAP, METALIZED POLY, T/R .1uF 10% C31-32
205-006-02 MICA 30PF 5% 500V T/A 30pF 5% C60
210-017-02 CAPACITOR, CERAMIC, T/R 470pF 5%/Y5E C45
212-001-00 CER .01UF 10% 50V X7R SM 0.01 10% C20 C25
212-006-00 CAPACITOR CERAMIC SMT 470PF 5% C46
212-007-00 CAPACITOR CERAMIC SMT 0.047 5% C4 C6 C8-10 C12-13 C22-23 C27 C30 C33
C35 C37-39 C41-42 C52-58 C61-62
212-008-00 CER .22UF +80/-20% 25V SM 0.22 5% C1 C3 C47 C51 C63
212-016-00 CAPACITOR CERAMIC SMT 1000PF 5% C5 C21 C24
212-018-00 CAPACITOR CERAMIC SMT 10PF 5% C43-44
212-019-00 CER 150PF 5% 50V SM 150PF 5% C11 C14
212-025-00 CAP CER .1UF 25V 10% X7R .1UF 10% C15-18 C66
212-029-00 CAPACITOR CERAMIC SMT 270PF 5% C34
220-001-02 CAPACITOR LYTIC RADIAL T&R 22UF 10% C7 C48-49 C64-65
220-004-02 CAPACITOR LYTIC RADIAL T&R 470UF 10% C50
220-014-00 CAPACITOR LYTIC RADIAL KS 2.2UF 10% C2 C19 C26 C28-29 C36 C40
300-003-00 DIODE SIGNAL SMD DL4148 D1-6 D11-14 D16-25 D27-36 D38-39
D41-42 D44-45 D47-52 D56-57
300-010-00 DIODE SIGNAL SMD RLS245 D26 D37 D40 D43 D46 D53-55 D58-60
302-009-00 DIODE ZENER SMD DL5260B D7 D10
302-010-03 DIODE ZENER SMD DL5232 D8-9 D15
310-042-00 XSTR NPN MJE15032 MJE15032 Q1
310-043-00 XSTR PNP MJE15033 MJE15033 Q2
311-001-00 X-SISTOR NPN SMD IMBT4401 Q13 Q22 Q25
311-002-00 X-SISTOR PNP SMD IMBT4403 Q7-8 Q21 Q24 Q28
311-007-00 TRANSISTOR PNP SMD 2SA1415 Q4 Q9-10 Q20
311-008-00 TRANSISTOR NPN SMD 2SC3645 Q3 Q11-12 Q15
311-009-00 TRANSISTOR PNP SMD 2SA1552 Q6 Q26
311-010-00 TRANSISTOR NPN SMD 2SC4027 Q5 Q27
311-011-00 TRANSISTOR PNP SMD 2SA1740 Q14
311-012-00 TRANSISTOR NPN SMD 2SC4548 Q23
311-019-00 TRANSISTOR PNP SMD 2SB792 Q16-17
311-020-00 TRANSISTOR NPN SMD 2SD814 Q18-19
320-012-00 OPAMP NJM4560M NJM4560M U5-6 U8-9
323-002-00 I.C. QUAD COMPARATOR SMD LM339 U2-4
329-014-00 IC, DEG C TEMP SENSOR LM35DZ U1
329-036-03 NJM4200M ANLG MULTR SM NJM4200 U7
400-143-00 CONN, HDR, 3-PIN, UN-SHROUDED 0 .100 J21-22
400-171-00 CONN, HDR, 2-PIN, UN-SHROUDED, 0 .100 J17-20 J23
400-186-00 CONN HDR 40P .100 X 2 STR SHRD J10
450-170-00 PCB, M2600 V-AMP & PROTECTION Z1
550-369-00 BRACKET, L H1-2
601-008-00 INDUCTOR 10uH L1-2
712-021-01 RIVET Z4-7
